Kodak NexPress SX3300 5 Color Digital Production Press

Sold Sold

The Kodak NexPress SX3300 is a digital production color press manufactured by Kodak. It is a high-end printing solution designed for commercial printing and production environments. Here are some key features and specifications of the Kodak NexPress SX3300:

1. Color Capability: The SX3300 offers 5-color printing, which includes CMYK (Cyan, Magenta, Yellow, and Black) plus a fifth color option. The fifth color can be used for spot colors, clear coating, or other special effects.
2. Resolution: It provides high-quality printing with a resolution of up to 600 x 600 dots per inch (dpi). This enables sharp and detailed images and text.
3. Printing Speed: The press can handle high-speed printing, capable of producing up to 4,200 A3/letter-size sheets per hour (2-up).
4. Substrate Compatibility: The NexPress SX3300 supports a wide range of substrates, including coated and uncoated papers, synthetics, labels, and more. It can handle various weights and sizes of paper, allowing for versatility in printing applications.
5. Inline Finishing Options: The press offers several inline finishing options to enhance the printed materials. These options may include coating, glossing, spot coating, metallics, varnishing, and more.
6. Variable Data Printing: Variable Data Printing (VDP) capabilities are available on the NexPress SX3300. This enables the personalization and customization of each printed piece, allowing for targeted and personalized marketing materials.
7. Workflow and Automation: The press integrates with Kodak's advanced workflow software, providing efficient and automated printing processes. This helps streamline production and reduces manual intervention.
8. Color Management: The NexPress SX3300 utilizes advanced color management technologies to ensure accurate and consistent color reproduction across print jobs.
9. Environmental Considerations: Kodak has implemented various environmental initiatives in the design of the NexPress SX3300, such as low energy consumption, reduced waste, and the use of environmentally friendly inks.

Kodak NexPress SX3300 5 color digital production color press

Manufacturer / Model: Kodak NexPress

Type: SX3300

Controller / RIP / Frontend:

Kodak Nexpress Dell front end – high performance

Kodak Nexpress Intelligent Calibration System ICS

Resolution: 600 dpi

HD Dry Ink Light Black, Black, Magenta, Yellow, Cyan, Clear, Gold, Metallic Clear, Dimensional Clear

Printing Speed: 100 A4/letter single-sided sheets per minute

4/0 and 5/0 print at same speed (no slowdown when printing 5 colors)

Paper Feeding: 2 feeders for each 4.500 sheets 2 feeders for each 1.000 sheets for a total capacity of 11.000 sheets

Substrate weights:

Standard Media:

Uncoated: 60 - 350 gsm

Coated: 80 - 350 gsm

Paper Delivery: 1 high-capacity delivery with a total pile height of 490mm, proof delivery of 500 sheets / 50mm

max. sheet size: 356 x 520 mm (14 x 20.47 in.)

min. sheet size: 279 x 200 mm (11 x 7.9 in.)

max. imageable area: 340 x 510 mm (13.4 x 20 in.)

Long Sheet Feeder sizes up to (14" x 39.37")

Maximum pile height:

570 mm (22.44 in.)

Maximum pile weight:

500 kg (1102 lb)

Installation: January 2020

Clicks: 11 mil A4
